The aluminum tread plate for sale is characterized by high hardness, strong durability, easy welding, corrosion resistance, etc. According to the different aluminum alloy, it can be divided into:
1. Aluminum-manganese alloy tread plate:
Processed with 3003 as the main raw material. This type of aluminum tread plate is also called rust-proof aluminum plate. Its strength is slightly higher than that of ordinary aluminum alloy tread plate. It has certain rust prevention properties, but has hardness and corrosion resistance it can’t reach 5000 series of aluminum tread plates, so this product is applied in non-strict anti-rust, such as truck models, cold storage floor.
2. Aluminum-magnesium alloy tread plate:
It is processed from 5000 series aluminum plates such as 5052 or 5083, which has good corrosion resistance, hardness, and rust resistance. Usually used in special places, such as ships, cabin lights in humid environments, this aluminum tread plate has high hardness and has a certain load-bearing capacity.
3. Ordinary aluminum tread plate:
The aluminum tread plate processed with 1060 aluminum plate as the base can adapt to the ordinary environment and the price is low. Usually used in cold storage, flooring, and outer packaging.
Alloy | 1050, 1060, 1100, 3003, 3105, 5005, 5052, 5754, 5454, 5083, 5086, 6061, 6082 | |
Temper | H114, H224, H12, H14, H16, H18, H32, H34, H36, H38, T4, T6, F | |
Surface | Bright Finish, Mill Finish | |
Bar Difference | Five Bar, Stucco, Compass, Diamond. | |
Available Dimension | ||
Mill Finish Surface | Bright Finish Surface | |
Thickness | 1.0---6.5mm | 1.2---6.5mm |
Pattern Height | Sheet Thickness: 1.0 - 2.0mm, Bar Height: 0.5mm | Sheet Thickness: 1.0- 2.0mm, Bar Height: 0.5mm |
Sheet Thickness: 1.0- 2.0mm, Bar Height: 1.0mm | Sheet Thickness: 1.0- 2.0mm, Bar Height: 1.0mm | |
Sheet Thickness Above 2.0mm, Bar Height: 1.5mm | Sheet Thickness Above 2.0mm, Bar Height: 1.5mm | |
Width | Maximum 1500mm | Maximum 1650mm |
Length | Maximum 6000mm | Maximum 6000mm |
Paper Interleaves | On Request For Selected | On Request For Selected |
Normal Size | 1200x2400mm, 1219x2438mm, 1219x3048mm | 1200x2400mm, 1219x2438mm, 1219x3048mm |
· Slip resistant surface
· Extremely durable—requires no maintenance
· Weather & corrosion resistant
· Bright reflective surface
· Unique decorative appearance
1. Floor Covering for hygiene and slip resistance
2. Door Protection as kick plates or as a full door cladding
3. Wall and Column Protection to prevent impact damage where hand trucks, trolleys, sack carts etc are operated.
4. Vehicle body, Vans, Trailer tailgate ramps and flooring.
5. Access Ramp covering for wheelchairs
6. Truck Bed, Tool Boxes
7. Stair Treads, Step Ladders, Walkways
