How much does a 4x8 sheet of aluminum diamond plate cost? That depends on the detailed specification, but Haomei offer reasonable price for you! Cost of 4x8 sheet of aluminum diamond plate also have relationship with the alloy, we know that the aluminum grade of 4x8 sheet of aluminum diamond plate are 1000 series, 3000 series and 5000 series. The aluminum diamond plate 4x8 sheet price of 1000 series are the lowest, followed by 3000 series aluminum diamond plate 4x8, and the 5000 series 4x8 aluminum diamond plate price are highest.
Item | 4x8 sheet of aluminum diamond plate |
Grade | 1050, 1060, 1100, 3003,5052, 5083, 5086, 6061 etc. |
Temper | O, H12, H14, H16, H18, H24, H24, H26, H32, H34 |
Standard | ASTM-B209. EN573-1, GB/T3880.1-2006 |
Thickness | 0.8 - 12mm |
Width | 400-1220mm |
Length | max 6000mm for sheet or as required for coil |
Pattern | 1 bar / diamond / pointer |
Surface treatment | polished, mill finished, power coated, sand blast, anodized, brushed. |
Surface Protection | Oleo phobic coating,protective film,paint coating. |
Packing | Export wooden pallets. The bundle weight not exceed 2MT. Loading:by 1x20GP. |
Quality | Totally free from defects like white rust, oil patches,roll marks, edge damage, camber, dents, holes, break lines, scratches and free from coil set. |
MOQ | 1-2 Metric ton |
Free sample | Available |
Delivery time | 20-30 days after deposit |
Anti-skid. It is benefit from the raised surface of the checker plate.
Anti-corrosion and rust. The aluminum and galvanized material can help the checker plate from the corrosive and dusty environments.
Anti-high temperature and alkaline.
Decorative. The bright surface, especially the polished aluminum checker plate has outstanding decorative affection.
Easy to install and economical. They are one-piece structure and lightweight, we can install them with few people and less cost.
1. Floor Covering for hygiene and slip resistance
2. Door Protection as kick plates or as a full door cladding
3. Wall and Column Protection to prevent impact damage where hand trucks, trolleys, sack carts etc are operated.
4. Vehicle body, Vans, Trailer tailgate ramps and flooring.
5. Access Ramp covering for wheelchairs
6. Truck Bed, Tool Boxes
7. Stair Treads, Step Ladders, Walkways
